Neware CE-7002-300V200A battery test system with 2 channels, 300V 200A output, regenerative high-power cycler for EV battery pack and energy storage testing.
Neware CE-7002-300V200A battery test system with 2 channels, 300V 200A output, regenerative high-power cycler for EV battery pack and energy storage testing.

Neware CE-7002-300V200A Battery Test System [2Ch, 300V 200A]

Neware CE-7002-300V200A Battery Test System [2Ch, 300V 200A] High-power regenerative battery pack testing system for EV batteries, energy storage systems, and industrial high-voltage battery validation. General Description The Neware CE-7002-300V200A Battery Test System is a high-power IGBT-based regenerative battery testing...
Vendor: Cell Lab
SKU: NW0035
Product type: Battery Equipment
£32,899.00
£32,899.00
Subtotal: £32,899.00
Description
Description
x

Neware CE-7002-300V200A Battery Test System [2Ch, 300V 200A]

High-power regenerative battery pack testing system for EV batteries, energy storage systems, and industrial high-voltage battery validation.

General Description

The Neware CE-7002-300V200A Battery Test System is a high-power IGBT-based regenerative battery testing platform engineered for advanced battery module, battery pack, and energy storage system validation. Designed for EV battery development, industrial battery manufacturing, and large-scale energy storage research, the system delivers high-current capability, rapid dynamic response, and stable high-voltage testing performance.

The system features 2 independent channels with programmable voltage from 30V to 300V and current output from 1A to 200A. Each channel supports up to 60kW output power, delivering a total system output power of 120kW for demanding battery testing applications.

Built on an IGBT regenerative architecture, the CE-7002 system enables discharge energy to be fed back to the power grid, significantly reducing energy consumption and operational costs. Advanced testing capabilities include constant current, constant voltage, constant power, constant resistance, dynamic simulation (SIM), cycle life testing, and programmable pulse operation.

The system also supports CANBus communication, parallel operation, auxiliary voltage and temperature monitoring, and Ethernet-based TCP/IP communication for automated industrial battery testing environments.

Key Features

High-Power 300V / 200A Testing Capability
Supports high-voltage battery module and pack testing with up to 60kW output power per channel.

IGBT Regenerative Energy Architecture
Recovered discharge energy can be returned to the power grid for improved efficiency and lower operating costs.

Advanced Dynamic Simulation Testing
Supports SIM testing with up to 1,000,000 programmable command lines for real-world battery simulation.

High-Speed Dynamic Response
Current response time up to 10 ms for dynamic charge and discharge applications.

Industrial Communication and Expansion Support
Supports CANBus, Ethernet TCP/IP communication, parallel operation, and auxiliary temperature/voltage monitoring.

Specifications

Parameter Specification
Model CE-7002-300V200A
Channels 2 independent
AC Input Voltage AC 380V ±10%, 50Hz / 60Hz
Input Power 133 kW
Input Current 203 A / Phase
Total Output Power 120 kW
Output Power per Channel 60 kW
Voltage Range 30V–300V
Minimum Discharge Voltage 30V
Voltage Accuracy ±0.1% FS
Voltage Stability ±0.1% FS
Current Range 1A–200A
Current Accuracy ±0.1% FS
CV Cut-off Current 1A
Current Stability ±0.1% FS
Power Stability ±0.2% FS
Current Response Time ≤10 ms
Minimum Data Record Interval 100 ms
Maximum Frequency 10 Hz
Charge Modes CC, CV, CCCV, CP
Discharge Modes CC, CP, CR
Simulation Modes Current, Voltage
Maximum SIM Command Lines 1,000,000
Maximum Cycles 65,535
Maximum Steps per Cycle 254
Cycle Nesting 3
Communication Protocol TCP/IP
Communication Port Ethernet
CANBus Communication Supported
Parallel Mode Supported
Database MySQL
Data Export Excel, TXT, CSV, PDF, Plot/Graph
Operating System Windows 7/8/10 64-bit
Noise <75 dB
Dimensions 1350 × 1000 × 1750 mm
Weight 1230 kg
Technical Data Sheet Click Here

Applications & Industries

  • EV battery module and pack testing
  • Energy storage system validation
  • High-voltage lithium battery testing
  • Dynamic battery simulation testing
  • Automotive battery R&D and manufacturing
  • Industrial battery durability validation
  • Battery safety and performance analysis

FAQ

What types of batteries can this system test?

The system is designed for high-voltage battery modules, battery packs, and energy storage systems.

Does the system support regenerative energy recovery?

Yes, discharge energy can be returned to the power grid to improve testing efficiency.

What simulation capabilities are supported?

The system supports SIM testing with programmable current and voltage simulation profiles.

Can the system operate in parallel mode?

Yes, parallel operation is supported for expanded testing capability.

Does the system support auxiliary temperature monitoring?

Yes, optional auxiliary channels support voltage and temperature monitoring with up to 248 auxiliary channels per main channel.
