Description
xCellLab Stainless Steel Roller Mill Jars [0.5 L – 15 L, Grade 304 & 316]
Durable Stainless Steel Jars for Medium-Hard & Brittle Sample Milling
CellLab 304 / 316 stainless steel roller mill jars are crafted for labs engaged in abrasive and brittle sample milling. With corrosion-resistant steel, secure anti-leak design, and minimal cross-contamination, these jars are suited for both dry and wet milling. All jars include lid, silicone sealing gasket, and clamps. Grinding media sold separately.
Key Features
-
Material: Stainless Steel (Grade 304 or Grade 316)
-
Corrosion resistant steel; suitable in harsh environments
-
Anti-leaking safe design with clamps for secure closure
-
Easy to clean, no dead ends, cylindrical form for efficient pour-out
-
Abrasion resistant; fair durability with medium-hard, brittle samples
-
Compatible with stainless steel grinding balls (grades 304 / 316); various diameters available
General Specifications
-
Max loading: 2⁄3 of jar volume
-
Density: approx. 8.0 g/cm³
-
Main chemical composition: Fe ~67–70.6%, Cr ~17–19%, Ni ~8–10%
-
Hardness: ≤187 HB
-
Suitable grinding ball diameters: 3 / 5 / 8 / 10 / 15 / 20 / 25 / 30 mm
-
Suitable for: medium-hard, brittle samples
Variant Specifications (sorted by volume)
| Product No. | Nominal Volume (ml) | Material Grade | Outer Ø (mm) | Inner Ø (mm) | Height (mm) |
| CL0430/ CL0431 | 500 | 304 / 316 | 88 | 82 | 144 |
| CL0432/ CL0433 | 1,000 | 304 / 316 | 106 | 100 | 172 |
| CL0434/ CL0435 | 2,000 | 304 / 316 | 131 | 124 | 206 |
| CL0436/ CL0437 | 3,000 | 304 / 316 | 158 | 152 | 217 |
| CL0438 / CL0439 | 5,000 | 304 / 316 | 178 | 172 | 269 |
| CL0440/ CL0441 | 10,000 | 304 / 316 | 243 | 233 | 307 |
| CL0442/ CL0443 | 15,000 | 304 / 316 | 271 | 263 | 347 |
Applications & Industries
Cell Lab stainless steel roller mill jars are ideal for mechanical alloying, powder homogenisation, and sample preparation involving medium-hard or brittle materials. They are widely used in:
-
Battery material research (cathode/anode powder mixing)
-
Metal and alloy powder production
-
Ceramic and composite material milling
-
Geological and metallurgical sample preparation
-
Research institutes, universities, and R&D laboratories requiring robust, contamination-resistant milling containers
FAQ
Q1: How do I choose between 304 and 316 stainless steel?
A: Grade 304 suits general laboratory use; Grade 316 offers higher corrosion resistance and is preferred for samples exposed to acids, chlorides, or moisture.
Q2: Can these jars be used for wet milling?
A: Yes. Each jar includes a silicone sealing gasket and clamping system ensuring leak-free wet milling performance.
Q3: Are the jars compatible with all roller mill systems?
A: The jars follow standard roller dimensions and are compatible with most bench-top and floor-type roller mills. Always check the roller spacing before operation.
Q4: What grinding media should I use?
A: Stainless steel balls (304 / 316) are recommended to avoid cross-contamination. Other media types can be used if hardness compatibility is confirmed.
Q5: How do I maintain the jar’s lifespan?
A: Avoid excessive impact energy, clean promptly after use, and store dry. Periodically inspect sealing gaskets and replace if signs of wear or deformation appear.
