Cell Lab Vacuum Drying Oven [Four-Sided Heating | PID Control | 24–214 L]

Cell Lab Vacuum Drying Oven [Four-Sided Heating | PID Control | 24–214 L] Reliable vacuum drying for heat-sensitive, decomposable, and oxidisable materials The Cell Lab™ Vacuum Drying Oven delivers uniform, precise, and safe low-pressure drying for sensitive samples such as...
Vendor: Cell Lab
SKU: DO0026
Product type: Drying Oven
£739.00
£739.00
Volume: 24L
Subtotal: £739.00
Description
Description
x

Cell Lab Vacuum Drying Oven [Four-Sided Heating | PID Control | 24–214 L]

Reliable vacuum drying for heat-sensitive, decomposable, and oxidisable materials

The Cell Lab™ Vacuum Drying Oven delivers uniform, precise, and safe low-pressure drying for sensitive samples such as polymers, powders, pharmaceuticals, and biological materials. Featuring four-sided heat conduction, vacuum decompression, and inert gas compatibility, it ensures exceptional performance in both research and industrial laboratories.

Key Features

• Four-Sided Thermal Conduction System
The chamber is heated on all four sides with direct shelf conduction, ensuring rapid, uniform drying even under low-pressure environments.

• Reliable Vacuum Integrity
A high-temperature silicone sealing ring and inflation port provide excellent airtightness, allowing stable long-term operation under vacuum.

• Dual-Layer Safety Observation Window
Equipped with explosion-proof tempered glass inside and a protective resin outer plate, the window maintains visibility while ensuring maximum operator safety.

• Intelligent PID Temperature Control
Two-stage PID controller offers 0.1 °C resolution, ±1 °C accuracy, and a programmable timer (0–9999 min) for accurate, repeatable thermal control.

• Laboratory-Grade Construction
Built with a stainless-steel inner chamber, electrostatic-sprayed steel exterior, and CE-certified aluminium-silicate insulation, the oven combines durability with thermal efficiency for continuous professional use.

Technical Parameters:

Model

DO0026

DO0027

DO0028

DO0029

Heating mode

Four walls heat conduction and decompression

Function

Temp.
Range

RT+10-250℃

Useful vacuum
degree Range

<133Pa

Temp.
Resolution Ratio

0.1℃

Temp. motion

±1℃

Heating-up
time

80min

100min

120min

120min

Structure

Inner Chamber

High quality stainless steel

Outer Shell

Cold rolling steel electrostatic spraying exterior

Insulation layer

High quality aluminum silicate cotton(with CE certification)

Heater

Stainless steel electric heat tube

Observation
window

Bullet proof tempered glass

Vacuum meter

Pointer type, accuracy class 2.5

Nozzle diameter

10mm

Power rating

0.8kW

1.4kW

2.0kW

3.0kW

Controller

Temp. control
mode

Two temperature section PID intelligent

Temp. setting
mode

Touch button setting

Temp. display
mode

Measuring temperature: display on the four digital tubes
upper row ; setting temperature: display on the
 lower row

Timer

0-9999min(with timing wait function)

Operation function

Fixed temperature operation, timing function, auto stop

Additional function

Sensor deviation correction, temperature overshoot
self-tuning, internal parameter locking,
power-off parameter memory

Sensor

pt100

Safety device

Over temperature sound-light alarm

Specification

Inner Chamber
size(W*L*H)
(mm)

300*300*270

415*370*340

450*450*450

550*600*650

Exterior size
(W*L*H)(mm)

480*480*606

560*540*680

640*590*780

740*740*1000

Packing size
(W*L*H)(mm)

590*550*750

704*620*814

739*700*889

839*850*1109

Volume

24L

52L

91L

214.5L

Standard Shelf Number

4

6

7

8

Load per rack

15kg

Shelf space

40mm

40mm

50mm

70mm

50/60HZ)
Current rating

AC220V

AC220V

AC220V

AC220V

NW/GW (kg）

42/52

67/92

82/105

170/200

Accessory

Shelf

2

Shelf frame

4

optional accessories

Silicone connecting tube, vacuum pump filter, vacuum pump

Applications & Industries

  • Pharmaceutical and biotechnology drying

  • Semiconductor and electronic component processing

  • Polymer and composite dehydration

  • Heat-sensitive chemical and biological sample preservation

  • Inert-gas drying of oxidisable materials

FAQ

Q1: What type of samples is this oven suitable for?
A1: It’s designed for heat-sensitive, decomposable, or oxidisable materials that require controlled vacuum or inert-gas environments.

Q2: How does four-sided heating improve performance?
A2: It ensures uniform temperature distribution and faster drying compared with single-sided or rear-heating designs.

Q3: Can it be connected to external vacuum pumps?
A3: Yes. It includes a 10 mm inflation port and supports external rotary-vane or diaphragm vacuum pumps.

Q4: Is the oven safe for continuous operation?
A4: Absolutely — it features temperature limiters, alarms, and CE-certified insulation for secure long-term use.

Q5: What materials are used in its construction?
A5: The inner chamber is made of SUS 304 stainless steel, while the outer shell is electrostatic-coated cold-rolled steel for corrosion resistance.
