Cell Lab TIMCAL SUPER C65 Nano Carbon Black [Ultra-Pure Conductive Additive for Cathode & Anode Electrodes] – High-Performance Carbon Black for Battery R&D

Ultra-pure nano carbon black for enhanced conductivity in lithium-ion battery electrodes

The Cell Lab TIMCAL SUPER C65 Nano Carbon Black is a high-purity conductive carbon additive specifically engineered for use in lithium-ion battery cathodes and anodes. Manufactured under strict quality control, it offers superior electrical conductivity, excellent dispersion, and extremely low metal impurities, ensuring optimal performance in both laboratory R&D and industrial scale-up environments.

Its sub-50 nm particle size and large BET surface area (63.2 m²/g) make it highly effective in reducing internal resistance, improving charge transfer, and enhancing electrode integrity during cycling. Ideal for high-energy density applications in EV, solid-state, and next-generation battery technologies.

Key Features

Ultra-High Purity for Advanced Applications
Trace metals (Fe, Ni, Co, V, Cu) each below 1 ppm, suitable for high-precision electrochemical research and solid-state battery development.

Enhanced Electrochemical Performance
Boosts both energy and power density while maintaining long cycle life and excellent thermal stability.

Optimised for Battery Slurry Preparation
No dispersing agent required; compatible with standard electrolyte systems (NMP, PVDF, and aqueous binders).

Superior Dispersibility and Process Control
Fine nano-scale structure (<50 nm) ensures uniform mixing with active materials for stable electrode formulation.

Low Moisture and Grit Content
Vacuum-sealed packaging and low volatile content (≤0.15%) enable immediate use after pre-baking at 150–200 °C.

Technical Specifications

Property Value
Form Powder
Country of Origin Belgium
CAS Number 1333-86-4
BET Surface Area 63.2 m²/g
Primary Particle Size <50 nm (TEM)
Volatile Content ≤ 0.15%
Ash Content (600°C) ≤ 0.010%
Toluene Extract ≤ 0.1%
Adsorption Stiffness 32 ml/5g
Moisture ≤ 0.1%
Density 0.16 g/cm³
Sulphur Content 0.02%
pH 9.4
Grit > 45 µm (325 mesh) <2 ppm
Grit > 20 µm (625 mesh) <10 ppm
Fe 1 ppm
Ni, Co, V, Cr, Cu <1 ppm each
Packaging Aluminium vacuum bag, air-tight

Applications & Industries

  • Cathode & Anode Slurry Additive – Enhances electronic conductivity and reduces impedance losses.

  • Solid-State & Next-Gen Batteries – Suitable for high-voltage and sensitive electrochemical systems.

  • Supercapacitors & Hybrid Energy Devices – Improves power delivery and charge efficiency.

  • Research & Pilot Production – Ideal for laboratory formulations and industrial scale-up validation.

  • EV Battery R&D Projects – Used in automotive-grade NCM/NCA cathodes and graphite/silicon anodes.

FAQ

Q1: Why choose TIMCAL SUPER C65 over Super P?
SUPER C65 features smaller particle size (<50 nm) and ultra-low metal impurities (<1 ppm), providing superior conductivity and purity for high-end applications.

Q2: Is it compatible with aqueous binders?
Yes, it is compatible with both NMP-based and water-based binder systems.

Q3: Do I need to pre-bake before use?
Yes, bake at 150–200 °C to remove adsorbed moisture for optimal slurry dispersion.

Q4: Can this be used in solid-state batteries?
Absolutely – its ultra-low impurity level makes it ideal for solid-electrolyte environments.

Q5: Is bulk custom packaging available?
Yes, custom bulk orders and volume pricing are available upon request.
