xCell Lab Sulphur–Carbon Composite Cathode Material [10 g, for High-Performance Lithium–Sulphur Batteries] – High-Capacity Sulphur Cathode for Next-Generation Energy Storage
Advanced sulphur–carbon composite optimised for high-energy lithium–sulphur battery research
The Cell Lab Sulphur–Carbon Composite Cathode Material is an advanced cathode powder designed for lithium–sulphur (Li–S) battery R&D. Engineered to overcome the key limitations of Li–S systems — such as polysulphide dissolution, volume expansion, and the low intrinsic conductivity of sulphur — this composite delivers enhanced electrical conductivity, stable cycling, and high reversible capacity.
Containing 75 wt% sulphur (customisable between 30–80%), this material achieves up to 1180 mAh/g at 0.1C, with excellent retention of 860 mAh/g after 100 cycles at 0.2C. It is pre-optimised for coin cell assembly and compatible with standard electrolytes and binders, making it ideal for both academic and industrial Li–S battery research.
Key Features
High Sulphur Content (75%)
Optimised composite for high energy density and improved electronic conductivity.
Outstanding Specific Capacity
Delivers an initial discharge capacity of 1180 mAh/g at 0.1C, ensuring superior active material utilisation.
Excellent Cycling Stability
Retains 860 mAh/g after 100 cycles at 0.2C under controlled laboratory conditions.
Customisable Sulphur Loading
Sulphur ratio adjustable from 30–80 wt% to match research requirements or cell design.
Coin Cell Compatibility
Validated performance in CR2032 configuration using conventional PVDF and carbon black binders.
Technical Specifications
| Parameter | Value |
|---|---|
| Appearance | Black powder |
| Composition | Sulphur–carbon composite |
| Sulphur Content | 75% (customisable 30–80%) |
| Particle Size (D10 / D50 / D90) | 5 µm / 15 µm / 33 µm |
| Tap Density | 0.37 g/cm³ |
| Package Size | 10 g / bottle |
Coin Cell Performance (CR2032)
| Condition | Performance |
|---|---|
| Electrode Composition | 91% S–C, 3% Ketjen Black, 6% PVDF |
| Electrolyte | 1 M LiTFSI + 2% LiNO₃ in DOL/DME (1:1) |
| Sulphur Loading | 5.5 mg/cm² (single-sided) |
| First Capacity @ 0.1C | 1180 mAh/g |
| Capacity after 50 cycles @ 0.1C | 1000 mAh/g |
| First Capacity @ 0.2C | 1090 mAh/g |
| Capacity after 100 cycles @ 0.2C | 860 mAh/g |
Applications & Industries
-
Lithium–sulphur battery cathode development
-
High-capacity electrode material research
-
Polysulphide-confinement and shuttle suppression studies
-
Advanced electrochemical material science
-
Academic and industrial Li–S battery prototyping
FAQ
Q1: What is the optimal sulphur content for high-performance Li–S cells?
Typically 70–80 wt% delivers the best balance between energy density and cycling stability.
Q2: Is this material compatible with standard Li–S electrolytes?
Yes. It performs well with ether-based electrolytes such as DOL/DME and additives like LiNO₃.
Q3: Can this be used directly for electrode preparation?
Yes. It can be mixed directly with PVDF and conductive carbon in NMP to form a homogeneous slurry.
Q4: Is it suitable for pouch or cylindrical cells?
Yes. The composite can be scaled for various cell formats depending on the slurry coating and loading.
Q5: Can sulphur content or particle size be customised?
Yes. Cell Lab offers tailored formulations (30–80 wt% S) and particle size adjustments upon request.
