Cell Lab Several Rows Magnetic Stirring Heating Mantles [Multi-Flask | Up to 450 °C | Optional Magnetic Stirring]

Cell Lab Several Rows Magnetic Stirring Heating Mantles [Multi-Flask | Up to 450 °C | Optional Magnetic Stirring] Versatile multi-unit heating with optional magnetic stirring up to 450 °C The Cell Lab™ Several Rows Magnetic Stirring Heating Mantle Series provides...
Vendor: Cell Lab
SKU: HM41A
Product type: Heating Mantles
£179.00
£179.00
Volume: A 2×100 ML
Subtotal: £179.00
Description
Description
x

Cell Lab Several Rows Magnetic Stirring Heating Mantles [Multi-Flask | Up to 450 °C | Optional Magnetic Stirring]

Versatile multi-unit heating with optional magnetic stirring up to 450 °C

The Cell Lab™ Several Rows Magnetic Stirring Heating Mantle Series provides efficient simultaneous heating — and stirring (for B-type models) — of multiple flasks for laboratory synthesis, distillation, and extraction. With electronic temperature regulation, durable nickel–chromium heating elements, and optional stepless stirring control, this series enables high-throughput reactions in chemical and industrial R&D.

Key Features

• High-Temperature Surface Conduction Heating
Each mantle uses nickel–chromium alloy heating wire for stable conduction up to 450 °C, ensuring uniform flask heating for reproducible results in organic synthesis and solvent evaporation.

• Dual-Function Models (A & B Types)
Model A provides temperature-controlled heating only, while Model B supports simultaneous heating + magnetic stirring with stepless speed adjustment (0 – 1400 rpm) for uniform mixing of liquid samples.

• Modular Multi-Flask Design
Available in 2-, 4-, and 6-flask configurations, each model accommodates 100 ml – 1000 ml round-bottom flasks. Custom multi-row or multi-capacity mantles can be produced to meet user-specific experimental setups.

• Durable Cold-Rolled Steel Housing
The outer shell is made from cold-rolled steel with corrosion-resistant powder coating, combining structural rigidity with an ergonomic laboratory design for long service life.

• Safe Continuous Operation
Incorporates electronic temperature regulation, over-temperature protection, and PTFE-coated stir bars (B-type). The system supports continuous operation under stable and controlled thermal conditions.

Main Parameters：




Model A

HM41A

HM42A

HM43A

HM44A

HM45A

HM46A

HM47A

HM48A

HM49A

HM50A

HM51A

HM52A



Model B



HM42B

HM43B

HM44B



HM46B

HM47B

HM48B



HM50B

HM51B

HM52B

Function

Specification(ml)

2×100

2×250

2×500

2×1000

4×100

4×250

4×500

4×1000

6×100

6×250

6×500

6×1000

Heating mode

Surface heat conduction

Surface Max. temperature

450℃

Temp. range

Rt+vfc20～250℃

Speed range

Model A :no/Model B：0～1400rpm

Structure

Heating element

Nickel chromium alloy wire

Stir bar

Model A :no /Model B：PTFE

Outer shell

Cold rolled steel plate, surface spraying

Motor power

Model A :no/Model B：0.01kW

Heating Power（kW）

2×0.1

2×0.15

2×0.25

2×0.35

4×0.1

4×0.15

4×0.25

4×0.35

6×0.1

6×0.15

6×0.25

6×0.35

Controller

Work model

Continuous

Specification

Exterior Size

 (mm)



280*140*106

320*160*170

360*180*180

420*210*200



530*140*160

610*160*170

690*180*180

810*210*200

820*140*160

940*160*170

1060*180*180

1240*210*200



Packing size(mm)

320*180*190

360*190*200

400*220*210

570*180*190

570*180*190

650*190*200

730*220*210

850*250*230

860*180*190

980*190*200

1100*220*210

1280*250*230

Voltage

100～120V or 200～240V

200～240V

N.W.(Kg)

4

4

4

7

8

8

8

14

12

12

12

21

G.W.(Kg)

5

5

5

8

10

10

10

16

15

15

15

24

Applications & Industries

  • Parallel chemical reactions and distillation

  • Organic and inorganic synthesis processes

  • Academic and industrial R&D laboratories

  • Heating and stirring of multiple solvent samples

  • Continuous process experiments and testing

FAQ

Q1: What’s the difference between Model A and Model B?
A1: Model A offers heating only, while Model B adds magnetic stirring (0–1400 rpm) with stepless speed control.

Q2: What is the maximum heating temperature?
A2: All models reach up to 450 °C with uniform surface heating for reliable thermal control.

Q3: Can custom multi-row mantles be made?
A3: Yes — Cell Lab can produce 2–6 row configurations or specific flask capacities upon request.

Q4: What is the recommended flask size range?
A4: Each row accommodates flasks from 100 ml to 1000 ml, depending on model selection.

Q5: Is continuous operation supported?
A5: Yes — each unit is designed for safe, continuous heating and stirring under regulated conditions.
