Cell Lab Porous Nickel Foam [High Porosity, Electrode-Ready Substrate] – 3D Conductive Nickel Matrix for Batteries and Catalysis

Lightweight, highly conductive nickel foam for advanced electrochemical and catalytic systems

The Cell Lab Porous Nickel Foam is a high-performance, three-dimensional metal substrate engineered for battery, supercapacitor, and catalysis applications. Featuring up to 97% porosity, this lightweight yet strong nickel matrix enables superior electron transport, efficient gas diffusion, and exceptional mechanical resilience.

With a uniform pore size of ~0.25 mm (110 PPI) and >99.8% nickel purity, it serves as a reliable electrode scaffold for thin-film deposition, in-situ catalyst growth, and high-rate electrochemical reactions. Its excellent chemical stability and high tensile strength make it ideal for both research and pilot-scale production.

Key Features

High Porosity and Excellent Conductivity
97% porosity with 110 PPI and ~0.25 mm pore size provides large surface area, efficient mass transport, and low internal resistance.

Superior Mechanical Strength
Longitudinal strength ≥95 N/cm² and elongation ≥5% ensure durability during electrode preparation and testing.

Electrode-Ready Conductive Matrix
Ideal for lithium-ion, sodium-ion, and supercapacitor systems requiring high current collection efficiency.

Chemically Stable Nickel Composition

99.8% Ni purity with trace-level impurities for outstanding oxidation and corrosion resistance.

Customisable Format Options
Standard size 300 mm × 200 mm × 0.3 mm; custom thicknesses and dimensions available upon request.

Technical Specifications：

Product Number CL0204
Material Nickel
Dimensions (L × W) 300 mm × 200 mm (customisable)
Thickness 0.3 mm (customisable)
Net Weight ~4 g
Surface Density 320 g/m²
Porosity 97% (110 pores per inch, PPI)
Pore Size ~0.25 mm
Longitudinal Strength ≥95 N/cm²
Longitudinal Elongation ≥5%
Transverse Strength ≥60 N/cm²
Transverse Elongation ≥10%
Chemical Composition Ni+Co ≥99.80%; Fe ≤0.02%; C ≤0.03%;P ≤0.2%; Cu ≤0.01%; Si ≤0.005%; S ≤0.008%

Applications & Industries

  • Lithium-ion and sodium-ion battery electrodes

  • Supercapacitors and hybrid energy storage systems

  • Hydrogen and oxygen evolution (HER/OER) catalyst supports

  • Electrocatalytic and water-splitting devices

  • EMI shielding, gas diffusion layers, and sensor substrates

FAQ

Q1: Can this nickel foam be used directly as an electrode substrate?
Yes. It can be used directly after cleaning or surface modification for slurry coating or in-situ catalyst growth.

Q2: How should the foam be pre-treated before use?
For best adhesion, clean the surface with dilute acid (e.g., 5% HCl) to remove oxides and rinse with deionised water.

Q3: Is the material suitable for high-temperature sintering or plating?
Yes. It maintains integrity up to 1000 °C in inert conditions, making it ideal for coating or CVD processes.

Q4: What is the difference between 110 PPI and 80 PPI foams?
110 PPI offers finer pores and greater surface area, while 80 PPI provides improved mechanical strength and faster gas diffusion.

Q5: Are roll formats or custom shapes available?
Yes. Cell Lab provides sheet and roll formats with tailored dimensions for pilot or industrial applications.
