Cell Lab Overhead Stirrer [LCD Control | High Torque | 20–40 L Mixing Capacity]

Cell Lab Overhead Stirrer [LCD Control | High Torque | 20–40 L Mixing Capacity] Large-capacity mechanical stirring with digital control and high torque The Cell Lab™ Overhead Stirrer Series is engineered for high-viscosity and large-volume liquid mixing in industrial, chemical,...
Vendor: Cell Lab
SKU: MS006
Product type: Overhead Stirrer
£369.00
£369.00
Type: Manual Overhead Stirrer, 20L
Subtotal: £369.00
Cell Lab overhead stirrer with LCD control and high torque handles 20–40 L mixing tasks. Brushless motor, programmable modes, and PID precision ensure stable performance for viscous materials.

Cell Lab Overhead Stirrer [LCD Control | High Torque | 20–40 L Mixing Capacity]

£369.00
Cell Lab overhead stirrer with LCD control and high torque handles 20–40 L mixing tasks. Brushless motor, programmable modes, and PID precision ensure stable performance for viscous materials.
Cell Lab overhead stirrer with LCD control and high torque handles 20–40 L mixing tasks. Brushless motor, programmable modes, and PID precision ensure stable performance for viscous materials.

Cell Lab Overhead Stirrer [LCD Control | High Torque | 20–40 L Mixing Capacity]

£369.00
Type: Manual Overhead Stirrer, 20L
Description
Description
x

Cell Lab Overhead Stirrer [LCD Control | High Torque | 20–40 L Mixing Capacity]

Large-capacity mechanical stirring with digital control and high torque

The Cell Lab™ Overhead Stirrer Series is engineered for high-viscosity and large-volume liquid mixing in industrial, chemical, biological, and materials laboratories. Featuring brushless DC motors, PID digital control, and programmable stirring modes, it ensures consistent torque output, smooth operation, and reliable long-term stability for demanding applications such as slurry, mud, and polymer solution preparation.

Key Features

• High-Torque, Long-Duration Performance
Driven by a brushless DC motor, the system provides continuous operation with strong torque and silent performance. Models range from 0.06 kW to 0.12 kW, supporting viscous samples up to 40 L and plate loads of 50 kg.

• Intelligent Control Modes (Digital Models)
Digital models (MS007 / MS008 / MS009) support three programmable stirring modes — Forward, Reverse, and Alternating — allowing precise control of mixing cycles for complex materials.

• LCD Display and Digital Timer (MS007–MS009)
Real-time monitoring of stirring speed and programmable timing (0–9999 min). The MS006 model uses an analogue scale dial for simple manual operation, while digital models feature fine-tuned electronic speed control and soft-start protection.

• Compact, Durable Construction
The reinforced plastic housing and stainless-steel head restraints ensure stability and durability under continuous operation. The 200 × 300 mm plate accommodates a wide range of vessel sizes for laboratory and industrial settings.

• Global Voltage Compatibility
Operating at AC 100–240V / 50–60Hz, all models are suitable for worldwide use. Compact dimensions and a 7–9 kg total weight make the series practical for bench and field environments alike.

Specifications:


Model

MS006

MS007

MS008

MS009

Function

Max. Volume(L)

20

20

40

40

digital

-

LCD

LCD

LCD

Speed(r.p.m)

100～2500

100～2500

100～2500

100～2500

Working time

Continous

Minimum revolution (r.p.m)

100

100

100

100

Structure

Exterior

Plastic shell

Driving mode

Motor

Motor power (kW)

0.06

0.06

0.08

0.12

Controller

Continuous operation

Yes

Setting mode

Scale

Digital

Digital

Digital

Speed display mode

Scale

Digital

Digital

Digital

Timer

No

Yes

Yes

Yes

Specification

Exterior size (W*L*H)(mm)

115×95×240

Packing size (W*L*H)(mm)

400×250×210

Plate size（mm）

200×300

Plate load

50KG

Power supply（50/60Hz）Current rating

100～240V

NW/GW (kg）

7/8

7/8

7.5/8.5

8/9

Applications & Industries

  • High-viscosity slurry and mud mixing

  • Polymer solution and coating preparation

  • Biochemical and pharmaceutical process stirring

  • Industrial liquid blending and homogenisation

  • Research and development laboratories

FAQ

Q1: What’s the difference between MS006 and MS009?
A1: MS006 uses manual scale control for basic mixing, while MS009 provides digital LCD display, programmable timing, and higher torque for viscous materials.

Q2: Can the stirrer operate continuously for long experiments?
A2: Yes — all models are built for continuous 24-hour operation with brushless motor technology.

Q3: What stirring volume can it handle?
A3: Depending on the model, up to 40 L of medium or high-viscosity liquid can be mixed efficiently.

Q4: Is it compatible with different voltages?
A4: Yes — it supports AC 100–240V, suitable for international laboratory setups.

Q5: Can the stirring direction be programmed?
A5: Yes — digital models allow forward, reverse, and alternating stirring for precise control.
