Cell Lab Orbital Shakers [LCD PID Control | Dual Amplitude | 100–500 rpm]

Precision-controlled cyclotron shaking for staining, fixation, and fluid agitation applications

The Cell Lab™ Orbital Shaker is designed for precision-controlled shaking in molecular biology, electrophoresis, and biochemical experiments. It delivers consistent orbital motion ideal for Coomassie staining, silver nitrate development, fixation of electrophoretic bands, and gentle fluid agitation. With brushless motor drive, LCD PID control, and modular tray options, it ensures stability, precision, and adaptability for various laboratory needs.

Key Features

• Dual Amplitude for Application Versatility
Two amplitude configurations: Φ10 mm (Model OS0001) for gentle mixing and Φ20 mm (Model OS0002) for vigorous shaking such as gel staining or large-sample decolorisation.

• Precise Speed Control with Built-In Safety
High-precision brushless DC motor offers ±1 rpm accuracy, intelligent low-speed start, and soft acceleration to prevent sample splashing. Integrated blocking protection automatically halts operation in case of mechanical obstruction.

• Intuitive LCD Interface & Rotary Dial Adjustment
A backlit LCD display provides real-time monitoring of speed and timing. The rotary encoder switch allows fast, precise setting of speed and operation time (up to 9999 minutes).

• Intelligent Memory & Power Recovery
Automatically resumes the previous working state after a power interruption. Includes deviation calibration, timing memory, and parameter lock to ensure uninterrupted workflow.

• Modular Platform Design
The anodised aluminium tray supports up to 5 kg load and is compatible with optional universal spring grids and flask clip trays (250 ml × 9 or 500 ml × 4), meeting diverse experimental demands.

Specifications:


Model

OS0001

OS0002

Shaking Mode

Cyclotron oscillation

Function

Amplitude

Φ10mm

φ20mm

Rotary Speed range

100~500rpm

30~250rpm

Rotary Speed Precision

±1rpm

Structure

Out Shell

ABS

Motor type

Brushless motor

Tray

Anodizing Alluminum

Driving mode

Four horizontal points

Power rating

0.03kW

Controller

Cyclotron Control Mode

LCD, PID intelligent control

Cyclotron Setting Mode

Rotary coding switch

Speed display Mode

LCD display

Timer

0～9999 min（with timing function）

Operation function

Fixed value operation、timing function、bidirectional automatic switchover、auto stop、quick stop start

Speed Sensor

Hoare

Additional funciton

Deviation calibration, power-off memory

Safety device

Intelligent low speed start, blocking protection

Specification

Exterior size (W*L*H)(mm)

365*450*222

Packing size (W*L*H)(mm)

470*550*325

Tray size （mm）

320*320

Load per tray

≤5kg

Tray Number

1

Supply（50/60Hz）Current rating

AC220V/0.14A

NW/GW (kg）

10/15

Optional Type

Universal spring grid  tray

Flask Clip Tray 250ml*9/500ml*4

Applications & Industries

  • Molecular biology and electrophoresis staining

  • Protein gel fixation and development

  • Biochemical sample decolorisation

  • Cell washing and reagent mixing

  • Laboratory education and teaching demonstrations

FAQ

Q1: What’s the difference between OS0001 and OS0002?
A1: OS0001 (Φ10 mm) provides gentle mixing, while OS0002 (Φ20 mm) offers stronger agitation for large-sample or staining applications.

Q2: Can it operate continuously for long durations?
A2: Yes, both models support 24-hour operation with built-in heat protection and stable brushless motor drive.

Q3: Does it have a memory function after power loss?
A3: Yes — it automatically restores the last working parameters and timing upon restart.

Q4: Are the trays interchangeable?
A4: Yes, both models use the same modular tray system compatible with grid or flask clip configurations.

Q5: What’s the recommended load limit?
A5: Each tray supports up to 5 kg, ensuring smooth and vibration-free operation even at high speeds.
