Cell Lab Lithium Nickel Manganese Cobalt Oxide (NMC 532) Powder [500g, D50 = 10–14 µm]
Cell Lab Lithium Nickel Manganese Cobalt Oxide (NMC 532) Powder [500g, D50 = 10–14 µm] High-performance NMC 532 cathode powder for advanced lithium-ion battery research The Cell Lab Lithium Nickel Manganese Cobalt Oxide (LiNi₀.₅Mn₀.₃Co₀.₂O₂, NMC 532) powder is a high-energy-density...
- £219.00
- £219.00
- Unit price
- per
Subtotal:
£219.00
Couldn't load pickup availability
Description
xCell Lab Lithium Nickel Manganese Cobalt Oxide (NMC 532) Powder [500g, D50 = 10–14 µm]
High-performance NMC 532 cathode powder for advanced lithium-ion battery research
The Cell Lab Lithium Nickel Manganese Cobalt Oxide (LiNi₀.₅Mn₀.₃Co₀.₂O₂, NMC 532) powder is a high-energy-density cathode material designed for next-generation lithium-ion batteries.
By optimising the nickel-to-manganese-to-cobalt ratio (5:3:2), this material achieves superior specific capacity, excellent thermal stability, and long cycle life, making it an ideal choice for both EV batteries and energy storage applications.
With a consistent D50 particle size of 10–14 µm, low metallic impurities, and excellent reproducibility, Cell Lab’s NMC 532 powder supports stable electrode fabrication, enhanced power output, and safe, high-voltage performance up to 4.4 V.
Key Features
-
Optimised Ni:Mn:Co = 5:3:2 Composition – Achieves a balance between high capacity, thermal stability, and cycle retention.
-
High Specific Capacity – Delivers 153–158 mAh/g (4.2 V) and up to 185 mAh/g (4.4 V) under laboratory test conditions.
-
Uniform Particle Distribution – D50 = 10–14 µm ensures consistent slurry coating and electrode density.
-
Low Impurity Content – Metallic contaminants such as Fe, Cu, Na, and Ca strictly limited for optimal long-term stability.
-
Versatile Cathode Performance – Suitable for both high-energy and high-power lithium-ion battery designs.
Technical Specifications
| Property | Value |
|---|---|
| Chemical Name | Lithium Nickel Manganese Cobalt Oxide |
| Molecular Formula | LiNi₀.₅Mn₀.₃Co₀.₂O₂ |
| Appearance | Black powder |
| Package Size | 500 g |
| Particle Size (D10 / D50 / D90) | ~5 µm / 10–14 µm / ≤ 25 µm |
| Pressed Density | ~2.3 g/cm³ |
| BET Surface Area | 0.2–0.5 m²/g |
| pH Value | ≤ 11.5 |
| First Discharge Capacity (0.2C) | 153–158 mAh/g (4.2 V) / 170–175 mAh/g (4.35 V) / 180–185 mAh/g (4.4 V) |
| First Discharge Efficiency | ~ 85 % |
Chemical Composition
| Element | Specification (wt %) | Typical Value (wt %) |
|---|---|---|
| Ni + Co + Mn | 58.5 – 60.5 | 58.83 |
| Li | 7.0 – 7.6 | 7.42 |
| Ca | ≤ 0.0100 | 0.0021 |
| Cu | ≤ 0.0020 | 0.0006 |
| Fe | ≤ 0.0050 | 0.0017 |
| Na | ≤ 0.0300 | 0.0077 |
Applications & Industries
-
Electric Vehicle Batteries – Delivers high energy density and long cycle life for automotive power cells.
-
Energy Storage Systems (ESS) – Maintains capacity stability and safety in high-voltage grid storage.
-
Battery R&D and Pilot Lines – Ideal for material evaluation, prototyping, and electrode optimisation.
-
Consumer Electronics – Suitable for compact, high-energy portable devices.
-
Power Tools and Industrial Equipment – Supports strong discharge capability and voltage consistency.
FAQ
Q1: What is the main difference between NMC 532 and NMC 622 or 811?
A: NMC 532 offers better thermal stability and longer cycle life than higher-nickel chemistries, making it safer for research and industrial use.
Q2: Can this powder be used for high-voltage testing (> 4.35 V)?
A: Yes. It is specifically formulated to support voltage windows up to 4.4 V, provided that appropriate electrolytes and binders are used.
Q3: What binder systems are recommended for slurry preparation?
A: Compatible with PVDF/NMP, CMC/SBR, and hybrid water-based systems.
Q4: How should the material be stored?
A: Store in a dry, inert atmosphere (Ar or N₂) to prevent surface oxidation and moisture absorption.
Q5: Is NMC 532 suitable for solid-state battery research?
A: Yes. It can be used with solid electrolytes after surface coating to improve interface compatibility.
