Description
xCell Lab Lithium Iron Phosphate (LFP) Powder [1.5 µm D50, Carbon Coated, 500 g]
High-performance carbon-coated LFP cathode material for lithium-ion batteries
The Cell Lab Lithium Iron Phosphate (LiFePO₄) Powder is a premium battery-grade cathode material engineered for advanced lithium-ion battery applications.
Featuring a carbon-coated surface, uniform particle distribution, and excellent electrochemical stability, this LFP powder ensures superior conductivity, safety, and long cycle life.
Widely adopted in EV batteries, energy storage systems, and laboratory-scale R&D, Cell Lab’s LFP exhibits a specific capacity exceeding 154 mAh/g at 0.1C with >95 % first-cycle efficiency, making it one of the most reliable materials for high-performance lithium cells.
Key Features
-
Carbon-Coated Surface – Improves electronic conductivity and enhances overall electrode kinetics for high-rate performance.
-
Optimised Particle Size – Median diameter (D50 = 1.5 µm) enables smooth slurry dispersion and uniform electrode coating.
-
High Specific Capacity – Delivers >154 mAh/g at 0.1C, maintaining >95 % coulombic efficiency.
-
Stable Electrochemical Performance – Provides excellent cycling retention and low internal resistance over extended use.
-
Industrial-Grade Purity – Synthesised via solid-state reaction under controlled carbon atmosphere for consistent quality.
Technical Specifications
| Property | Value |
|---|---|
| Chemical Name | Lithium Iron Phosphate |
| Molecular Formula | LiFePO₄ |
| Formula Weight | 157.76 g/mol |
| Appearance | Carbon-coated black powder |
| Package Size | 500 g |
| Particle Size (D10 / D50 / D90) | 0.55 µm / 1.5 µm / 6.0 µm |
| Tap Density | 0.8 ± 0.2 g/cm³ |
| BET Surface Area | 10–14 m²/g (typ. 11.7 m²/g) |
| pH Value | 9.5 ± 1.0 |
| Moisture | < 1000 ppm (typ. ~700 ppm) |
| Refractive Index | 1.65 – 1.70 |
| Electrical Resistance | < 100 Ω·cm (typ. 7.23 Ω·cm) |
| First Discharge Efficiency (0.1C) | > 95 % (typ. 97.6 %) |
| First Capacity (0.1C) | > 154 mAh/g |
Chemical Composition (wt %)
| Element | Content |
|---|---|
| Li | 4.0 – 4.5 % |
| Fe | 32.0 – 35.0 % |
| P | 18.0 – 20.0 % |
| Mn | 0.3 % |
| Pb | 0.01 % |
| C | 1.3 – 1.5 % |
Applications & Industries
-
Lithium-Ion Battery Cathodes – Core material for LFP-based lithium-ion cells.
-
EV Power Batteries – Provides thermal stability and long cycle life for electric vehicles.
-
Energy Storage Systems (ESS) – Ensures safe, high-efficiency performance in large-scale grid storage.
-
Battery Research & Prototyping – Ideal for laboratory R&D and pilot cell manufacturing.
-
Consumer Electronics – Stable, low-cost cathode option for high-safety applications.
FAQ
Q1: What is the advantage of carbon-coated LFP compared to uncoated LFP?
A: The carbon coating enhances conductivity, reduces internal resistance, and improves high-rate charge–discharge performance.
Q2: Is this material compatible with standard NMP-based cathode slurry formulations?
A: Yes. It disperses well in both PVDF/NMP and water-based binder systems (such as CMC/SBR).
Q3: What is the recommended calcination temperature for re-coating or surface modification?
A: Typically between 600–700 °C under inert or reducing atmosphere, depending on the carbon precursor used.
Q4: Can it be used in full-cell or half-cell testing?
A: Yes. It is suitable for both coin-cell and pouch-cell configurations, matched with graphite or LTO anodes.
Q5: How should the powder be stored?
A: Store in airtight containers in a dry, inert atmosphere (argon or nitrogen) to prevent surface oxidation.
