Cell Lab Laboratory Precision Hot Plate Series

Cell Lab Laboratory Precision Hot Plate Series [320–400°C | Aluminium & Graphite Heating Plates] High-uniformity laboratory hot plates with analogue or digital temperature control for chemical heating, sample drying, materials research and laboratory thermal processing. General Description The Cell Lab...
Vendor: Cell Lab
SKU: IB0077
Product type: Hot Plates
£469.00
£469.00
Size & Temperature: 300 × 300 mm 320°C
Subtotal: £469.00
Description
Description
x

Cell Lab Laboratory Precision Hot Plate Series [320–400°C | Aluminium & Graphite Heating Plates]

High-uniformity laboratory hot plates with analogue or digital temperature control for chemical heating, sample drying, materials research and laboratory thermal processing.

General Description

The Cell Lab Laboratory Hot Plate Series is designed for precise and stable heating applications in chemical laboratories, research institutes, materials science, electronics and industrial testing environments. Available with either aluminium alloy heating plates or high-temperature graphite plates, the series provides rapid thermal response, excellent surface temperature uniformity and reliable continuous heating performance.

The product line includes both analogue control models and digital display models, supporting maximum operating temperatures from 320°C to 400°C. Digital variants provide clearer temperature monitoring and improved heating precision, while graphite heating plate versions deliver superior high-temperature resistance for demanding laboratory applications.

With multiple plate sizes available, the series is suitable for sample evaporation, solution heating, material drying, wafer processing, battery research and general laboratory thermal treatment.

Key Features

• Fast and uniform heating performance — Optimised heating structure ensures rapid thermal transfer and stable plate temperature distribution.

• Aluminium or graphite plate options — Select aluminium alloy plates for general laboratory heating or graphite plates for higher temperature applications.

• Digital display temperature monitoring — Digital models provide clear real-time temperature visibility and improved operational precision.

• Multiple plate sizes available — Supports laboratory workflows ranging from small benchtop testing to larger batch heating processes.

• Durable industrial-grade construction — Iron plate welded housing with corrosion-resistant sprayed exterior for long-term laboratory use.

Model Variants

SKU Plate Size Max Temperature Plate Material Display Type Voltage
IB0077 300 × 300 mm 320°C Aluminium Plate Analogue 220V / 110V
IB0078 350 × 450 mm 320°C Aluminium Plate Analogue 220V
IB0079 400 × 600 mm 320°C Aluminium Plate Analogue 220V
IB0080 300 × 300 mm 350°C Aluminium Plate Digital Display 220V / 110V
IB0081 350 × 450 mm 350°C Aluminium Plate Digital Display 220V
IB0082 400 × 600 mm 350°C Aluminium Plate Digital Display 220V
IB0083 300 × 300 mm 400°C Graphite Plate Digital Display 220V / 110V
IB0084 350 × 450 mm 400°C Graphite Plate Digital Display 220V
IB0085 400 × 600 mm 400°C Graphite Plate Digital Display 220V

Technical Specifications

General Specifications

Parameter Specification
Outer shell Iron plate welding with surface spraying
Temperature sensor K-type thermocouple
Timer No / Digital depending on model
Power supply 220V / 50–60Hz
Heating method Surface conduction heating
Heating uniformity Optimised uniform plate temperature
Application type Laboratory heating & thermal processing

Heating Power

Plate Size Analogue 320°C Digital 350°C Graphite 400°C
300 × 300 mm 800 W 1200 W 1800 W
350 × 450 mm 1500 W 2400 W 3000 W
400 × 600 mm 2200 W 3500 W 4500 W

Temperature Accuracy

Model Type Temperature Accuracy
Analogue models ±10%
Digital display models ±1%

Plate Temperature Uniformity

Model Type Uniformity
Analogue models ±15%
Digital display models ±10%

Mechanical Specifications

Plate Size Exterior Dimensions (W × L × H) Plate Load
300 × 300 mm 340 × 370 × 220 mm 20 kg
350 × 450 mm 420 × 500 × 220 mm 30 kg
400 × 600 mm 470 × 650 × 220 mm 40 kg

Applications & Industries

  • Chemical laboratory heating
  • Battery material research
  • Graphene and advanced materials testing
  • Sample drying and evaporation
  • Semiconductor and wafer heating
  • Industrial thermal processing
  • University and research laboratories
  • Pharmaceutical laboratory heating

SEO Keywords: laboratory hot plate, graphite hot plate, digital laboratory hot plate, aluminium heating plate, high temperature lab heater, chemical laboratory heater, laboratory heating plate

FAQ

Q1: What is the difference between aluminium and graphite hot plates?

Aluminium plates provide fast and uniform general-purpose heating, while graphite plates support higher temperatures and improved thermal resistance.

Q2: Which models include digital temperature display?

IB0080–IB0085 feature digital display temperature control systems.

Q3: What is the maximum operating temperature?

Maximum temperature ranges from 320°C to 400°C depending on the model configuration.

Q4: Are different voltages available?

Selected models support both 220V and 110V configurations.

Q5: Which industries commonly use graphite hot plates?

Graphite hot plates are widely used in battery research, semiconductor processing, advanced materials development and high-temperature laboratory testing.
