Cell Lab Hot Air Sterilizing Drying Oven [Forced Convection | PID Control | 30–230 L]

Cell Lab Hot Air Sterilizing Drying Oven [Forced Convection | PID Control | 30–230 L] High-temperature dry-heat sterilisation for glassware, instruments, and materials The Cell Lab™ Hot Air Sterilising Drying Oven provides uniform, reliable, and rapid dry-heat sterilisation for laboratory...
Vendor: Cell Lab
SKU: DO0014A
Product type: Drying Oven
£509.00
£509.00
Volume: 30L (A model)
Subtotal: £509.00
Description
Description
x

Cell Lab Hot Air Sterilizing Drying Oven [Forced Convection | PID Control | 30–230 L]

High-temperature dry-heat sterilisation for glassware, instruments, and materials

The Cell Lab™ Hot Air Sterilising Drying Oven provides uniform, reliable, and rapid dry-heat sterilisation for laboratory glassware, instruments, and other heat-resistant materials. Featuring forced-air convection, two-stage PID temperature control, and multi-layer safety protection, it ensures stable, precise, and repeatable results for microbiological, pharmaceutical, and industrial laboratories.

Key Features

• Forced-Air Convection System
Dual horizontal air ducts and a high-temperature-resistant blast motor deliver rapid, even heat transfer across the chamber for maximum thermal uniformity.

• Accurate PID Temperature Control
Advanced two-section PID controller offers 0.1 °C resolution and ±1 °C accuracy, with a temperature range of RT + 10 °C to 300 °C, ensuring consistent sterilisation and drying performance.

• Superior Temperature Uniformity
Achieves ±2.5 % temperature uniformity across all shelves, enabling precise and reproducible results in repeated sterilisation cycles.

• Durable and Safe Construction
Built with a mirror-finish SUS304 stainless-steel inner chamber, cold-rolled steel outer shell with electrostatic coating, and CE-certified rock-wool insulation for durability and thermal efficiency.

• Intuitive Control Interface
Available in A type (LED) and B type (LCD) models, both featuring touch-button operation, fixed-temperature and timer modes (0–9999 min), auto-stop, and memory retention after power loss.

• Enhanced Safety Protection
Includes sound-and-light over-temperature alarms, independent mechanical/digital limiters, and fan-speed regulation (B series) for safe and reliable long-term operation.

Technical Parameters:


Model

DO0014A

DO0015A

DO0016A

DO0017A

DO0018A

DO0019A

DO0014B

DO0015B

DO0016B

DO0017B

DO0018B

DO0019B

 Cycle Mode

Forced convection


Function

Temp. range

RT+10-300℃

Temp. Resolution Ratio

0.1℃

Temp. Motion

±1℃

Temp. Uniformity

±2.5%


Structure

Inner Chamber

Mirror Stainless Steel

Outer Shell

Cold rolling steel electrostatic spraying exterior

Insulation layer

High quality rock wool board(with CE)

Heater

stainless steel heater

Power rating

0.8kW

1.2kW

1.6kW

2.0kW

2.3kW

3.0kW

Exhaust hole

Φ35mmtop(with function of test hole)


Controller

Temp. control mode

Two temperature section PID intelligent

Temp. setting mode

Touch button setting

Temp. display mode

A model:LED Digital Display

B model: LCD Digital display

Timer

0-9999min(with timing wait function)

Operation function

Fixed temperature operation, timing function, auto stop.

Additional Function

A model: Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory

B model: Mechanical independent temperature limiter, 3-grade adjustable speed fan (DO0018B without fan speed adjustor),
sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory

 Sensor

PT100

Safety Device

A type: Over temperature sound-light alam;

B type: Digital Independent Temp. imiter, Over temperature sound-light alam.


Specification

Inner Chamber size(W*L*H)(mm)

310*310*310

350*350*350

400*360*450

450*420*450

500*450*550

600*500*750

Exterior size (W*L*H)(mm)

460*510*695

500*550*735

550*550*840

590*610*830

636*680*915

735*835*1115

Packing size (W*L*H)(mm)

540*575
*855

580*615
*895

635*625
*995

680*685
*1000

710*730
*1100

857*885
*1287

Volume

30L

45L

65L

85L

125L

230L

Shelf number

5

6

8

8

11

17

Load per rack

15kg

Shelf space

40mm

Current rating (50/60HZ)

AC220V/3.6A

AC220V/5.5A

AC220V/7.2A

AC220V/9.0A

AC220V/10.5A

AC220V/13.6A

NW/GW (kg）

33/37

37/43

44/49

50/56

60/66

94/120


Accessory

Shelf

2

Shelf frame

4

optional accessories

A model: Spare shelf;

B model: Spare shelf, RS485 interface,
printer, program controller, U-disk storage; 3.5-inch color touch screen temperature controller,SUS304 body.

Applications & Industries

  • Dry-heat sterilisation of glassware and metal instruments

  • Heat conditioning of materials and powders

  • Pharmaceutical and biotechnology laboratories

  • Industrial quality control and component testing

  • Research and educational laboratories

FAQ

Q1: What’s the difference between A and B models?
A1: The A type features LED display and standard PID control; the B type adds LCD interface, independent temperature limiter, and fan-speed adjustment.

Q2: What is the maximum temperature range?
A2: The oven supports RT + 10 °C to 300 °C, suitable for dry-heat sterilisation of most glassware and metal tools.

Q3: Can it be used for continuous operation?
A3: Yes — it is engineered for long-term operation with stable temperature control and CE-certified thermal insulation.

Q4: Is it compatible with laboratory data logging systems?
A4: Yes, the B series includes RS485 and USB interfaces for data export and integration with external recording systems.

Q5: How does it ensure safety during sterilisation?
A5: Through multi-layer protection — independent limiters, audible/visual alarms, and high-temperature rock-wool insulation to prevent overheating.
