Cell Lab FTIR heating die set with dual-channel heating. Durable Cr12MoV steel, 15–100 μm thin-film pellet preparation for spectroscopy, chemistry, and materials research.
Cell Lab FTIR heating die set with dual-channel heating. Durable Cr12MoV steel, 15–100 μm thin-film pellet preparation for spectroscopy, chemistry, and materials research.

Cell Lab 50 mm FTIR Quantitative Heating Die Set [Double Channel, up to 400 °C]

Cell Lab 50 mm FTIR Quantitative Heating Die Set [Double Channel, up to 400 °C] Precision heating die set for high-quality FTIR sample preparation General Description The Cell Lab 2" (50 mm) FTIR Quantitative Heating Die Set is designed for...
Vendor: Cell Lab
SKU: CL0702
Product type: Pellet Press Die Set
£3,619.00
£3,619.00
Subtotal: £3,619.00
Description
Description
x

Cell Lab 50 mm FTIR Quantitative Heating Die Set [Double Channel, up to 400 °C]

Precision heating die set for high-quality FTIR sample preparation

General Description

The Cell Lab 2" (50 mm) FTIR Quantitative Heating Die Set is designed for preparing uniform thin-film pellets required in Fourier Transform Infrared (FTIR) spectroscopy. Featuring a double-channel heating system with a wide temperature range (ambient to 400 °C), this die ensures precise temperature control for reproducible sample quality.

Constructed from Cr12MoV alloy tool steel with an indenter hardness of HRC60–62, the die offers outstanding strength, durability, and resistance to wear. Its flat heating design allows preparation of 15–100 μm thick samples, suitable for demanding FTIR applications in materials science, chemistry, and pharmaceuticals.

Key Features

  1. High-temperature capability — Dual-channel heating with adjustable control up to 400 °C.

  2. Precision FTIR performance — Produces 50 mm flat pellets with consistent thickness (15–100 μm).

  3. Durable alloy steel construction — Made from Cr12MoV (AISI D2 equivalent), hardened to HRC60–62.

  4. Flexible press compatibility — Works with hydraulic, lever, or arbor presses for different laboratory setups.

  5. Laboratory-ready design — Optimised for spectroscopy, thin-film studies, and advanced material analysis.

Specifications

Product No. Type Sample Size Sample Thickness Cavity Depth (mm) Heating Range Power Voltage Die Material Hardness Dimensions (mm) Weight
CL0702 FTIR Flat Heating Die Φ50 mm 15–100 μm 5 0–400 °C 300 W 220 V / 50 Hz Cr12MoV Alloy Steel HRC60–62 200 × 60 13 kg

Applications & Industries

  • FTIR spectroscopy — Thin-film pellet preparation for accurate IR absorption studies.

  • Material science — Sample heating and compaction for polymers, composites, and catalysts.

  • Chemistry & pharmaceuticals — FTIR quality control, drug formulation, and molecular analysis.

  • Thin-film research — Preparation of uniform layers for optical and chemical analysis.

  • Academic & industrial labs — Advanced spectroscopy in R&D and routine testing.

FAQ

Q1: What is the advantage of the double-channel heating system?
It provides uniform heat distribution and precise temperature control up to 400 °C, ensuring reproducible pellet quality.

Q2: What thickness of samples can be prepared?
The die can produce thin-film pellets between 15–100 μm, depending on sample material and press settings.

Q3: Which presses are compatible with this die?
It can be used with hydraulic, lever, or arbor presses, depending on the force required.

Q4: What is the recommended maintenance?
Clean after each use, store in a dry environment, and apply protective oil if unused for long periods.

Q5: Is the die covered under warranty?
It is considered a consumable. Warranty only applies to manufacturing defects; normal wear and rust are excluded.

Sample Shape:

Diagram Of Press Die:
