Cell Lab 3N (99.9%) Titanium Monoxide (TiO) Pieces and Tablets – High-Purity Evaporation Materials

Advanced Conductive Oxide Material for Thin-Film and Semiconductor Research

General Description

Cell Lab 3N Titanium Monoxide (TiO) Evaporation Materials are high-purity inorganic compounds supplied in both pieces and tablet forms, ideal for thin-film deposition, microelectronics, and optical coating applications. Titanium monoxide exhibits low electrical resistivity and excellent thermal stability. Its defect rock-salt crystal structure allows for conductivity and diffusion barrier efficiency, making it particularly useful in layered semiconductor structures. With growing interest in visible-light absorption, TiO is also emerging as a promising material in optoelectronic and photocatalytic research.

Key Features

  • High Electrical Conductivity – Functions as a stable diffusion barrier against Al and Si interdiffusion in microelectronic devices.

  • Excellent Thermal and Chemical Stability – Retains structural integrity and purity under high vacuum and temperature.

  • Dual-Form Availability – Supplied in 3–6 mm pieces and 8–9 mm tablets for flexible research and industrial setups.

  • Versatile Thin-Film Applications – Suitable for TiO-based coatings, diffusion barriers, and optoelectronic devices.

  • Customisable Options – Dimensions, form factor, and purity can be adjusted upon request for R&D or bulk production.

Technical Specifications

Parameter Specification
Name Titanium Monoxide
Chemical Formula TiO
CAS Number 12137-20-1
Molecular Weight 63.88 g/mol
Appearance Dark, Crystalline Solid
Purity 99.9% (3N)
Melting Point 1750 °C
Theoretical Density 4.95 g/cm³
E-Beam Compatibility Good
Thermal Evaporation Boat W, Mo
Crucible Material Vitreous Carbon
E-Beam Crucible Liner Material Graphite, Tantalum
Vapour Pressure Temperature (Torr) 10⁻⁴: ~1500 °C

Product Variants

SKU Form Dimensions Pack Size
ST0008 Pieces 3–6 mm 50 g
ST0009 Pieces 3–6 mm 100 g
ST0010 Tablets 8–9 mm × 6–7 mm 50 g
ST0011 Tablets 8–9 mm × 6–7 mm 100 g

Applications & Industries

  • Thin-film deposition and semiconductor coating

  • Microelectronic layered structures and diffusion barriers

  • Photocatalytic and optoelectronic research

  • Advanced material synthesis and optical experiments

  • Research in visible-light absorption and energy materials

FAQ

Q1: What makes Titanium Monoxide unique among titanium oxides?
TiO is a conductive suboxide with a defect rock-salt structure, offering both metallic and ceramic characteristics—unlike TiO₂, which is an insulator.

Q2: Can TiO be used in microelectronic diffusion barriers?
Yes. Its low resistivity and thermal stability make it an effective diffusion barrier between Al and Si layers.

Q3: What forms are available for purchase?
Both 3–6 mm pieces and 8–9 mm × 6–7 mm tablets are offered, in 50 g or 100 g packs.

Q4: Are larger or purer versions available?
Yes. Cell Lab provides custom dimensions and purity grades upon request for R&D and industrial-scale applications.
