Cell Lab 1200°C Vacuum Box Furnace [7.2L, Atmosphere Furnace]
Cell Lab 1200°C Vacuum Box Furnace [7.2L, Atmosphere Furnace] High-Precision Vacuum Furnace with Uniform Heating & Programmable PID Control The Cell Lab 7.2L Vacuum Box Furnace is a compact, high-performance laboratory furnace designed for controlled atmosphere heat treatment, material calcination,...
- £6,986.00
- £6,986.00
- Unit price
- per
Subtotal:
£6,986.00
Description
xCell Lab 1200°C Vacuum Box Furnace [7.2L, Atmosphere Furnace]
High-Precision Vacuum Furnace with Uniform Heating & Programmable PID Control
The Cell Lab 7.2L Vacuum Box Furnace is a compact, high-performance laboratory furnace designed for controlled atmosphere heat treatment, material calcination, sintering, and advanced R&D applications. Featuring three-sided heating and intelligent PID temperature control, it ensures excellent thermal uniformity and process stability.
With programmable multi-stage heating profiles and reliable vacuum capability, this system is ideal for materials science, battery research, ceramics, and catalyst activation processes. The integrated safety system and high-quality insulation materials significantly enhance operational efficiency and equipment lifespan.
Key Features
-
Three-Sided Heating for Uniform Temperature Distribution
Heating elements positioned on the left, right, and top provide rapid heating rates and highly uniform temperature fields, improving experimental consistency. -
Advanced PID Control with 30 Programmable Segments
Intelligent temperature control system with fuzzy PID regulation allows precise multi-stage programming for complex thermal processes. -
High-Purity Insulation for Energy Efficiency
Furnace chamber constructed with alumina polycrystalline fibre reduces heat loss and improves energy efficiency by up to 50%. -
Vacuum & Controlled Atmosphere Capability
Supports vacuum operation (up to -0.1 MPa) and protective gas introduction, enabling oxidation-sensitive and advanced material processing. -
Comprehensive Safety Protection System
Equipped with over-temperature alarms, automatic power cut-off, and thermocouple fault detection to ensure safe and stable operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CL0893 |
| Chamber Volume | 7.2 L |
| Chamber Size | 200 × 300 × 120 mm |
| Maximum Temperature | 1200°C (short-term) |
| Continuous Temperature | 1150°C |
| Heating Rate | Recommended ≤ 20°C/min |
| Temperature Accuracy | ±1°C |
| Control System | Fuzzy PID + 30-step programmable |
| Heating Elements | High-quality HRE alloy wire |
| Vacuum Degree | Up to -0.1 MPa |
| Rated Power | 2.5 kW |
| Voltage | 220V / 50Hz |
| Dimensions | 450 × 500 × 610 mm |
| Weight | 160 kg |
Applications & Industries
- Battery materials research (lithium-ion, solid-state)
- Catalyst activation and calcination
- Powder metallurgy & sintering
- Ceramic and advanced materials processing
- University laboratories and R&D centres
- Vacuum heat treatment of sensitive materials
FAQ
1. Can this furnace operate under vacuum and inert gas conditions?
Yes, the system supports both vacuum operation and protective gas introduction (e.g., argon), making it suitable for oxygen-sensitive materials.
2. What is the maximum continuous working temperature?
The furnace can operate continuously at 1150°C and reach up to 1200°C for short-term applications.
3. Does the furnace support programmable heating profiles?
Yes, it includes a 30-segment programmable PID control system for complex heating and cooling processes.
4. What materials are used for insulation?
High-purity alumina polycrystalline fibre is used, offering excellent thermal insulation and energy efficiency.
5. Is the temperature uniformity reliable for research use?
Yes, the three-sided heating design ensures uniform temperature distribution across the chamber.
